High Flow capacity Ring lock series quick disconnect Pneumatic Quick Coupling
CB-12 Series ring lock series quick disconnect pneumatic couplings have a unique interchange which designed for use with compressed air.
Applications • Shipyards • General Pneumatics • Mining • Marine
Standard Materials
Features
| Body Size | PARTNO. | Thread | A | B | HEX |
| 1/4" | CB-S1S-12MN-K | 1/8-27 | 2.01 | 1.06 | 0.88 |
| 1/4" | CB-S2S-12MN-K | 1/4-18 | 2.16 | 1.06 | 0.88 |
| 1/4" | CB-S3S-12MN-K | 3/8-18 | 2.16 | 1.06 | 0.88 |
| 1/4" | CB-S4S-12MN-K | 1/2-14 | 2.35 | 1.06 | 0.88 |
| Body Size | PARTNO. | Thread | C | D | HEX |
| 1/4" | CB-P1S-12MN-K | 1/8-27 | 1.51 | 0.58 | 0.50 |
| 1/4" | CB-P2S-12MN-K | 1/4-18 | 1.66 | 0.65 | 0.56 |
| 1/4" | CB-P3S-12MN-K | 3/8-18 | 2.04 | 0.79 | 0.69 |
| 1/4" | CB-P4S-12MN-K | 1/2-14 | 2.31 | 1.01 | 0.88 |
