Home /Products/Quick Connect Products/ISO9001 Hydraulic Brass Quick Disconnect Fittings

ISO9001 Hydraulic Brass Quick Disconnect Fittings

Negotiation
MOQ
Negotiation
Price
ISO9001 Hydraulic Brass Quick Disconnect Fittings
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Brass Hydraulic Quick Coupler
Material: Brass
Connection: Female/Male
Technics: CNC Machining
Size: 1/8' ~ 1'
Temperature: -20~120°C
Standard: ISO7241B
Certification: ISO9001
Highlight:

ISO9001 Brass Quick Disconnect Fittings

,

ISO7241B Brass Quick Disconnect Fittings

,

IATF16949 brass quick connect water fittings
Basic Infomation
Place of Origin: Shanghai, China
Brand Name: carterberg
Certification: IATF16949
Model Number: CB-3
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 7-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000~20000 pc/month
Product Description

Medium-pressure High Performance Pneumatic And Hydraulic Brass Quick Coupling


Carterberg products can be applied widely to the joints and terminals of mechanical equipments, fire protection, shipping, military equipments, medical, aviation, metallurgy, chemical and power equipments.



CB-3 Series Quick Couplings are used across the spectrum of hydraulic applications. Primarily used with hydraulic fluid. CB-3 couplings are also used with chemicals, water, steam, and some gases.

Standard Materials

  • Brass, zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Poppet valves available to prevent uncoupled leakage . Poppet valves open automatically when coupled within rated working pressure to keep the flow expeditely.
  2. Critical parts are hardened for durability.
  3. Compatible with PARKER 60 Series, FASTER HNV Series AEROQUIP FD45 Series and HANSEN HK Series.

ISO9001 Hydraulic Brass Quick Disconnect Fittings 0

Body SizePARTNO.ThreadABAcross Flats
1/8"CB-S1B-1FG1/8-271.910.980.56
1/8"CB-S1B-1FN1/8-271.910.980.56
1/4"CB-S2B-1FG1/4-192.261.170.75
1/4"CB-S2B-1FN1/4-182.261.170.75
3/8"CB-S3B-1FG3/8-192.561.420.88
3/8"CB-S3B-1FN3/8-182.561.420.88
1/2"CB-S4B-1FG1/2-142.961.861.13
1/2"CB-S4B-1FN1/2-142.961.861.13
3/4"CB-S6B-1FG3/4-143.482.221.31
3/4"CB-S6B-1FN3/4-143.482.221.31
1"CB-S8B-1FG1-114.132.611.75
1"CB-S8B-1FN1-11ISO9001 Hydraulic Brass Quick Disconnect Fittings 14.132.611.75

ISO9001 Hydraulic Brass Quick Disconnect Fittings 2

Body SizePARTNO.ThreadCDEHEX
1/8"CB-P1B-1FG1/8-271.260.650.440.56
1/8"CB-P1B-1FG1/8-271.260.650.440.56
1/4"CB-P2B-1FG1/4-191.520.870.560.75
1/4"CB-P2B-1FN1/4-181.520.870.560.75
3/8"CB-P3B-1FG3/8-191.761.010.610.88
3/8"CB-P3B-1FN3/8-181.761.010.610.88
1/2"CB-P4B-1FG1/2-142.031.300.761.13
1/2"CB-P4B-1FN1/2-142.031.300.761.13
3/4"CB-P6B-1FG3/4-142.361.520.711.31
3/4"CB-P6B-1FN3/4-142.361.520.711.31
1"CB-P8B-1FG1-112.851.880.971.63
1"CB-P8B-1FN1-11ISO9001 Hydraulic Brass Quick Disconnect Fittings 12.851.880.971.63

ISO9001 Hydraulic Brass Quick Disconnect Fittings 4


Tag:

SS316 1 Inch Hydraulic Quick Coupler

IATF16949 1 Inch Hydraulic Quick Coupler

BSP hydraulic hose quick disconnect fittings
