1/4'' Applications in Air Tools High flow Brass Pneumatic Quick Coupling
CB-12 Series High flow, automatic Quick-Connect Couplings designed for use with compressed air.
Applications & Markets
• General Pneumatics
• Air Tools
• Construction
Features
| Body Size | PARTNO. | Thread | A | B | HEX |
| 1/4" | CB-S2B-12FN-G | 1/4-18 | 2.02 | 0.94 | 0.81 |
| 1/4" | CB-S2B-12FG-G | 1/4-19 | 2.02 | 0.94 | 0.81 |
| 1/4" | CB-S3B-12FN-G | 3/8-18 | 2.02 | 0.94 | 0.81 |
| 1/4" | CB-S3B-12FG-G | 3/8-19 | 2.02 | 0.94 | 0.81 |
| 1/4" | CB-S4B-12FG-G | 1/2-14 | 2.34 | 0.94 | 1.06 |
| Body Size | PARTNO. | Thread | C | D | HEX |
| 1/4" | CB-P1S-12FN | 1/8-27 | 1.47 | 0.65 | 0.56 |
| 1/4" | CB-P2S-12FN | 1/4-18 | 1.63 | 0.79 | 0.69 |
| 1/4" | CB-P3S-12FN | 3/8-18 | 1.69 | 0.94 | 0.81 |
| 1/4" | CB-P2B-12FN | 1/4-18 | 1.63 | 0.78 | 0.69 |
| 1/4" | CB-P2L-12FN | 1/4-18 | 1.63 | 0.79 | 0.69 |
