1/4'' Nominal Male End Connections Industrial Interchange Pin Lock Couplings Brass Pneumatic Quick Coupling

Negotiation
MOQ
Negotiation
Price
1/4'' Nominal Male End Connections Industrial Interchange Pin Lock Couplings Brass Pneumatic Quick Coupling
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Quick Coupler
Application: Gases
Standard: NPT
Thread: Male
Pressure: 1.6Mpa
Temperature: -20℃ ~ 120℃
Usage: Oil Gas Water Industrial
Size: Everything You Need
Highlight:

Brass Pneumatic Quick Coupling

,

1/4 Nominal Male End Connections

,

Industrial Interchange Pin Lock Couplings
Basic Infomation
Place of Origin: Shanghai, China
Brand Name: carterberg
Certification: IATF16949
Model Number: CB-S2B-12MN
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 7-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000~20000 pc/month
Product Description

1/4'' Nominal Male End Connections Industrial Interchange Pin Lock Couplings Brass Pneumatic Quick Coupling



CB-S2B-12MN are used compressed air, gases, and liquids.



Standard Materials

  • Brass, zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Rugged, reliable
  2. Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket end of line
  3. Compatible with PARKER 20 Series, Rectus 23KA Series, Hansen 3000 Series, CEJN 310 Series

Rated Pressure and Flow Capacity

BODY SIZE Rated Pressure (PSI) Rated Pressure (BAR)

Flow Capacity

(scfm)

 Standard seal material
1/4" 2000 138 28 NBR

1/4'' Nominal Male End Connections Industrial Interchange Pin Lock Couplings Brass Pneumatic Quick Coupling 0

Body Size PARTNO. Thread A B HEX
1/4" CB-S1B-12MN 1/8-27 2.11 1.19 0.69
1/4" CB-S2B-12MN 1/4-18 2.26 1.19 0.69
1/4" CB-S3B-12MN 3/8-18 2.26 1.19 0.69
1/4" CB-S4B-12MN 7/16-20* 2.20 1.19 0.69
1/4" CB-S5B-12MN 5/8-18 2.33 1.19 0.75

1/4'' Nominal Male End Connections Industrial Interchange Pin Lock Couplings Brass Pneumatic Quick Coupling 1

Body Size PARTNO. Thread C D HEX
1/4" CB-P1S-12MN 1/8-27 1.59 0.58 0.50
1/4" CB-P2S-12MN 1/4-18 1.75 0.65 0.56
1/4" CB-P3S-12MN 3/8-18 1.75 0.79 0.69
1/4" CB-P2B-12MN 1/4-18 1.75 0.64 0.56
1/4" CB-P2L-12MN 1/4-18 1.75 0.65 0.56



Our Services:

1. Customized design, OEM is available.
2. In-time & professional after sales service.
3. Low MOQ, standard package, fast delivery.
4. Special discount and protection are provided to our distributors.
5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature.
