1/4'' Nominal Brass compressed air quick release coupling Pneumatic Quick Coupling

Negotiation
MOQ
Negotiation
Price
1/4'' Nominal Brass compressed air quick release coupling Pneumatic Quick Coupling
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Quick Coupler
Application: Industry
Standard: BSP BSPT NPT
Thread: 1/4
Type: Coupling
Pressure: 1.6Mpa
Temperature: -20℃ ~ 120℃
Usage: Oil Gas Water Industrial
Highlight:

Pneumatic Quick Coupling

,

1/4 Brass Quick Coupling

,

Compressed Air Quick Coupling
Basic Infomation
Place of Origin: Shanghai, China
Brand Name: carterberg
Certification: IATF16949
Model Number: CB-S2B-12FN
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 7-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000~20000 pc/month
Product Description

1/4'' Nominal Brass Pneumatic Quick Coupling

CB-S2B-12FN are used compressed air, gases, and liquids.



Standard Materials

  • Brass, zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Rugged, reliable
  2. Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket end of line
  3. Compatible with PARKER 20 Series, Rectus 23KA Series, Hansen 3000 Series, CEJN 310 Series

Rated Pressure and Flow Capacity

BODY SIZE Rated Pressure (PSI) Rated Pressure (BAR)

Flow Capacity

(scfm)

 Standard seal material
1/4" 2000 138 28 NBR

1/4'' Nominal Brass compressed air quick release coupling Pneumatic Quick Coupling 0

Body Size PARTNO. Thread A B HEX
1/4" CB-S1B-12FN 1/8-27 1.95 1.19 0.69
1/4" CB-S2B-12FN 1/4-18 2.17 1.19 0.69
1/4" CB-S3B-12FN 3/8-18 2.23 1.19 0.75

1/4'' Nominal Brass compressed air quick release coupling Pneumatic Quick Coupling 1

Body Size PARTNO. Thread C D HEX
1/4" CB-P1S-12FN 1/8-27 1.47 0.65 0.56
1/4" CB-P2S-12FN 1/4-18 1.63 0.79 0.69
1/4" CB-P3S-12FN 3/8-18 1.69 0.94 0.81
1/4" CB-P2B-12FN 1/4-18 1.63 0.78 0.69
1/4" CB-P2L-12FG 1/4-18 1.63 0.79 0.69



Our Services:

1. Customized design, OEM is available.
2. In-time & professional after sales service.
3. Low MOQ, standard package, fast delivery.
4. Special discount and protection are provided to our distributors.
5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature.
