BSPP ISO Coupler , 5000PSI Hydraulic Quick Coupler

Negotiation
MOQ
Negotiation
Price
BSPP ISO Coupler , 5000PSI Hydraulic Quick Coupler
Features Gallery Product Description Request A Quote
Features
Specifications
Standard: ISO5675
Material: Steel
Name: HYDRAULIC QUICK COUPLING
Pressure: 3000-5000
Size: 1/4-1
Flow: 3-50
Thread: BSPP/NPT
Mainly: Fluid
Highlight:

BSPP ISO Coupler

,

ISO5675 ISO Coupler

,

5000PSI Hydraulic Quick Coupler
Basic Infomation
Place of Origin: Shanghai, China
Brand Name: carterberg
Certification: IATF16949
Model Number: CB-4
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 7-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000~20000 pc/month
Product Description

ISO5675 Standard CLOSE TYPE HYDRAULIC QUICK COUPLING



Features

  1. Poppet valves available to prevent uncoupled leakage . Poppet valves open automatically when coupled within rated working pressure to keep the flow expeditely.
  2. Critical parts are hardened for durability.
  3. Poppet valves open automatically when coupled, within rated working pressure, to keep the flow expeditely.
  4. Critical parts are hardened for durability.
  5. conforms to the standard of ISO5675.
  6. Compatible with PARKER 4000 Series and FASTER NV/NS Series.

CB-4 Series hydraulic quick couplings are mainly used for construction equipment , forestry equipment, hydraulic machinery and oil equipment and other required hydraulic applications.

Standard Materials

  • zinc-plated steel
  • Seals: NBR, Viton, EPDM



BSPP ISO Coupler , 5000PSI Hydraulic Quick Coupler 0

Body Size PARTNO. Thread A B Across Flats
1/8" CB-S1S-1FG 1/8-27 1.91 0.98 0.56
1/8" CB-S1S-1FN 1/8-27 1.91 0.98 0.56
1/4" CB-S2S-1FG 1/4-19 2.26 1.17 0.75
1/4" CB-S2S-1FN 1/4-18 2.26 1.17 0.75
3/8" CB-S3S-1FG 3/8-19 2.56 1.42 0.88
3/8" CB-S3S-1FN 3/8-18 2.56 1.42 0.88
1/2" CB-S4S-1FG 1/2-14 2.96 1.86 1.13
1/2" CB-S4S-1FN 1/2-14 2.96 1.86 1.13
3/4" CB-S6S-1FG 3/4-14 3.48 2.22 1.31
3/4" CB-S6S-1FN 3/4-14 3.48 2.22 1.31
1" CB-S8S-1FG 1-11 4.13 2.61 1.75
1" CB-S8S-1FN 1-11 4.13 2.61 1.75

BSPP ISO Coupler , 5000PSI Hydraulic Quick Coupler 1

Body Size PARTNO. Thread C D E HEX
1/8" CB-P1S-1FG 1/8-27 1.26 0.65 0.44 0.56
1/8" CB-P1S-1FG 1/8-27 1.26 0.65 0.44 0.56
1/4" CB-P2S-1FG 1/4-19 1.52 0.87 0.56 0.75
1/4" CB-P2S-1FN 1/4-18 1.52 0.87 0.56 0.75
3/8" CB-P3S-1FG 3/8-19 1.76 1.01 0.61 0.88
3/8" CB-P3S-1FN 3/8-18 1.76 1.01 0.61 0.88
1/2" CB-P4S-1FG 1/2-14 2.03 1.30 0.76 1.13
1/2" CB-P4S-1FN 1/2-14 2.03 1.30 0.76 1.13
3/4" CB-P6S-1FG 3/4-14 2.36 1.52 0.71 1.31
3/4" CB-P6S-1FN 3/4-14 2.36 1.52 0.71 1.31
1" CB-P8S-1FG 1-11 2.85 1.88 0.97 1.63
1" CB-P8S-1FN 1-11 2.85 1.88 0.97 1.63
