Applications of Stainless Steel Flexible Control Shafts in Tanker Systems
Built for Tanker Control Precision
Phidix’s tanker control shafts are engineered to meet the complex routing, environmental, and safety demands found in modern tanker vehicles. From fuel distribution to chemical transport, these stainless steel flexible shafts ensure reliable mechanical control, even under corrosive, high-vibration, or extreme temperature conditions.
Each shaft integrates a sealed conduit structure, corrosion-resistant fittings, and a flexible routing profile, enabling precise control in limited spaces without rigid linkages.
Key Application Scenarios
1. Fuel Tanker Discharge & Valve Actuation
• Manual or remote valve control (e.g., bottom-loading, vapor return)
• Emergency shutdown systems
• Shaft routes through chassis bends to access tank valves
Shaft Requirement: Low backlash, smooth stroke under vibration, corrosion-proof
2. Chemical Tanker Operations
• Handles chemical-resistant control for pumps, valves, or pressure relief
• Routed in sealed conduit systems to prevent external contamination
• Operates reliably despite exposure to acidic or alkaline environments
Shaft Requirement: Fully stainless-steel fittings, non-absorbent conduit, sealed ends
3. Food-Grade / Sanitary Tankers
• Used for sanitary valve control (e.g., CIP ports, bottom outlets)
• Requires smooth external finish and minimal particle retention
• Often installed in refrigerated trailers or temperature-sensitive zones
Shaft Requirement: Smooth outer sheath, -50°C low-temp resistance, no lubricant leakage
4. Multi-Tank Compartment Control Systems
• Controls multiple mechanical outputs from a single operator station
• Includes linkages to hydraulic valve banks, mechanical actuators, or interlocks
• Reduces need for electrical wiring in flammable transport systems
Shaft Requirement: Flexible core, multi-path routing, synchronized mechanical response
Why Choose a Flexible Shaft over Rigid Control Rods?
| Flexible Shaft |
Rigid Rod |
| Bends around corners and tanks |
Requires straight paths |
| Stainless steel & sealed structure |
Corrodes or loosens over time |
| Handles vibration and thermal shifts |
Misalignment risk under chassis movement |
| Easier maintenance and modular repair |
Full-length replacement often needed |
Common Models for Tanker Use
• Phidix Tanker Shaft PTS-400 Series
• Custom stroke ranges: 80–300 mm
• Operating temperature: −50°C to +110°C
• Available with clevis, rod-end, or locking-style terminals
