Adjustment Free Car Gear System , HGS 925 Series Car Gear Shift Controller

Adjustment Free Car Gear System , HGS 925 Series Car Gear Shift Controller

  • High Light

    custom manual shifter

    ,

    car gear shift

  • Name
    Car Transmission System
  • Model Number
    925 Series
  • Recommended Handle Lengths
    305mm To 380mm (12" - 15" Approx.
  • Normal Working Load @ Knob
    3.0kg (6.6lb.)
  • Accidental Overload @ Knob
    100kg (220lb.)
  • Material
    Pressure Die-cast Aluminum
  • Operating Temperatures
    -40°C To 120°C (-40°F To 248°F)
  • Place of Origin
    China
  • Brand Name
    PHIDIX
  • Certification
    IATF16949
  • Model Number
    HGS925
  • Minimum Order Quantity
    1 Piece/Pieces
  • Price
    Negotiation
  • Packaging Details
    carton or wood case
  • Delivery Time
    7-40 work days
  • Payment Terms
    L/C, D/A, D/P, T/T
  • Supply Ability
    888 Piece/Pieces per Month

Adjustment Free Car Gear System , HGS 925 Series Car Gear Shift Controller



Manual Transmission System Gear Shifter HGS 925 Series Gear Shift Controller



【 Product Description 】

For many years, the transportation industry has searched for a reliable shift system which is able to replace the maintenance-prone and cumbersome rod linkages which are commonly used in rear engine buses and in cab over trucks. This need has increased, resulting in vehicles which have become more refined. These include the complexities of floating cabs, specialty vehicles of every type and curb noise restrictions.
A systems approach has been developed which makes remote shifting easier for both the operator and the vehicle builder. The system offers a maintenance-free and cost-effective approach to remote manual transmission shifting which has been based on the proven performance and quality of low friction control cables.
We are able to solve the most challenging shifting problems with their full range of cab units and transmission connecting hardware which is able to suit most applications.

Adjustment Free Car Gear System , HGS 925 Series Car Gear Shift Controller 0



【 Features 】
• Easy installation,adjustment free
• Maintenance-free life
• Ends gear jump out
• Clean precise shifts
• No knob-to-cab relative movement in floating

   cabs
• No action required to tilt cab
• Vibration from drive train is not transmitted
• Reduced cab noise levels
• Low cost
• Installation design to customer requirements
• Flexible capability with different cable end fittings

【 Material 】

Housing

Pressure Die-cast Aluminum

Yoke & Select Arm

Investment Cast Steel

Options

• Fully Sealed Unit Available

• Gaiter Available

• Different End Fittings Available

• Right & Left Hand Configurations

• With or Without Bias Spring

• Adjustable Bias Spring Position

• Variable Ratio Between 4:1 to 5:1
